ABB E530 servo drives
ABB E530 servo drives are general-purpose servo drives with rich functions. Available in two variants—pulse train input (E530-PT) and EtherCAT (E530-EC)—they support position, torque, and speed control modes. E530-PT uses pulse train, analog input, and Modbus TCP/IP, while E530-EC supports EtherCAT for high-precision communication. Combined with DSM servo motors, they offer high cost-performance servo systems
Technical Specifications
Voltage: Single/three phase 200–240 V AC, three phase 380–480 V AC (-15%/10%)
Power range: 0.2 kW to 7.5 kW
High-speed loop response: 2 kHz
Maximum pulse train I/O frequency: 4 MHz (E530-PT)
Minimum EtherCAT cycle: 250 μs (E530-EC)
Features: Built-in braking resistor (≥0.75 kW), UV-coated PCB, compact side-by-side mounting, Ethernet interface for easy commissioning
Protocols: Modbus TCP/IP (E530-PT), EtherCAT (E530-EC)
Compatibility: ETG conformance, compatible with mainstream EtherCAT controllers
Power range: 0.2 kW to 7.5 kW
High-speed loop response: 2 kHz
Maximum pulse train I/O frequency: 4 MHz (E530-PT)
Minimum EtherCAT cycle: 250 μs (E530-EC)
Features: Built-in braking resistor (≥0.75 kW), UV-coated PCB, compact side-by-side mounting, Ethernet interface for easy commissioning
Protocols: Modbus TCP/IP (E530-PT), EtherCAT (E530-EC)
Compatibility: ETG conformance, compatible with mainstream EtherCAT controllers
